| Reflective type Detector EPS-607 uses Infrared light as the light source of detection, emitting light to material edge and receiving the reflective light from target, checking the material edge position in transmission. Because just installing detector of single case, it saves space and don’t need to adjust light axis, the detection is accurate, whether the materials are transparent, black mesh or blank color. |
|
|
 |
 |
|
| Edge Position Detector EPS-607 |
 |
 |
| System |
|
| Detection method |
Reflective type Infrared light |
| Power |
±12Vdc 200mA |
| Toggle-switch |
Power ON-OFF control |
| Lighting source |
Infrared LED |
| Receiver |
Photosensitive transistor |
| Detection range |
8mm |
| Emitting diameter |
12mm |
| Receiving range |
12mm |
| Response speed |
10 ms |
| Ambient temperature |
0°C ~45°C |
| Ambient humidity |
35 - 85% RH (No condensation) |
| Environment requirement |
No corrosive, no combustible gas, no conductive dust |
| Weight |
0.7Kg |
| Applicable controller |
AMP-1151, EPD-335, EPD-3008&P, GK-6000 |
|
|
|
| Mechanic data |
|
| Connection |
Cable |
| Mounting |
Fixed rack |
| Housing |
Aluminum |
| Dimension |
Refer to “Dimension Diagram” |
|
|
|
| Electric data |
|
| Output detection signal |
DC ±8V, 5mA max. |
|
|
 |
|
 |
 |
 |
 |
 |
 |
 |
